HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding

HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding

1000Hz Technology Spot Welding Machine

Vertical Type Medium Frequency Inverter Spot Welder

Consistent Metal Sheet Welding DC Spot Welder

Tempat asal:

Cina

Nama merek:

Hwashi

Sertifikasi:

CE

Nomor model:

WL-CD-5K

Hubungi kami

Permintaan Penawaran
HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding
HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding
Rincian Produk
Nama Produk:
HWASHI WL-MF-250K Mesin Pengelasan Titik Lembar Logam Tipe Vertikal Frekuensi Menengah Inverter
Jaminan:
12 bulan
Ukuran:
850x900x1850*mm
Berat:
450kg
Standar:
CE/CCC/ISO
Kehidupan pelayanan:
8-10 tahun
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order
1
Harga
Dapat dinegosiasikan
Kemasan rincian
Paket kayu yang layak di laut
Waktu pengiriman
7-30 hari kerja setelah menerima pembayaran Anda
Syarat-syarat pembayaran
T/T,L/C
Menyediakan kemampuan
50 Set per Bulan
Produk-produk terkait
Harga yang pantas HWASHI WL-MF-250K Vertikal Type Medium Frequency Inverter Spot Welding Machine dengan Teknologi 1000Hz untuk Pengelasan Lembar Logam Konsisten on line video

HWASHI WL-MF-250K Vertikal Type Medium Frequency Inverter Spot Welding Machine dengan Teknologi 1000Hz untuk Pengelasan Lembar Logam Konsisten

Dapatkan Harga Terbaik
Harga yang pantas HWASHI WL-MF-250K Vertikal Type Medium Frequency Inverter Spot Welding Machine dengan Teknologi 1000Hz untuk Pengelasan Lembar Logam Konsisten on line video

HWASHI WL-MF-250K Vertikal Type Medium Frequency Inverter Spot Welding Machine dengan Teknologi 1000Hz untuk Pengelasan Lembar Logam Konsisten

Dapatkan Harga Terbaik
Harga yang pantas HWASHI WL-MF-250K Mesin Pengelasan Titik Inverter Frekuensi Menengah Tipe Vertikal dengan Teknologi Inverter 1000Hz dan Arus Pengelasan DC on line video

HWASHI WL-MF-250K Mesin Pengelasan Titik Inverter Frekuensi Menengah Tipe Vertikal dengan Teknologi Inverter 1000Hz dan Arus Pengelasan DC

Dapatkan Harga Terbaik
Harga yang pantas Mesin Las Titik AC Berdenyut yang Dapat Disesuaikan Hwashi untuk Aplikasi Industri Perangkat Keras on line video

Mesin Las Titik AC Berdenyut yang Dapat Disesuaikan Hwashi untuk Aplikasi Industri Perangkat Keras

Dapatkan Harga Terbaik
Hubungi kami
+86-13380655800
export_trade@hwashi.com
86-752-3528326
Hubungi sekarang
Deskripsi Produk
HWASHI WL-MF-250K Vertical Medium Frequency Inverter Spot Welding Machine
Vertical type medium frequency inverter spot welding machine designed for consistent metal sheet welding results with advanced 1000Hz inverter technology.
Advanced Inverter Technology
The MF Inverter Spot Welder utilizes three-phase power supply converted through specialized inverter technology to generate 1000Hz AC voltage. This is then transmitted to a medium frequency transformer and rectified to supply DC welding current for superior performance.
Technical Advantages
  • Significantly reduces energy consumption in iron core materials by increasing frequency from 50/60Hz to 1000Hz
  • Transformer commutation diodes convert electrical energy into efficient DC welding power
  • Dramatically improves inductance coefficient while minimizing production costs
  • DC welding circuit virtually eliminates energy loss associated with inductance coefficient
HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding 0
HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding 1
Premium Construction Features
HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding 2
Thicker copper plates or copper belts ensure stable conductivity during welding operations.
HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding 3
Customized electrodes suitable for various materials including steel, aluminum, silver, stainless steel, and nickel steel.
HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding 4
Optimized structure design with custom machine shapes and molds designed according to specific welding product requirements.
Key Features
  • Three-phase power supply with grid balance and minimal grid impact
  • High power factor of 0.7-0.9 (compared to 0.4 for power frequency)
  • Superior welding control accuracy with 1000Hz+ inverter frequency
  • 20x higher control capability than AC welding machines
  • Excellent welding quality with stable nugget size and minimal spatter
  • Reduced grid power demand - only 2/3 of AC resistance welding machines
  • Short welding times and extended electrode life
  • User-friendly interface with multiple welding specifications storage
  • Real-time monitoring of welding current, time, pressure, and cooling water flow
Technical Specifications
Model WL-MF-100K
Input Power (V/φ) 380/3
Rated Power (KVA) 100
Applicable Material Stainless Steel, Carbon steel, Aluminum, Metal
Max Short Circuit Current (KA) 21
Electrode Force (KG) 1000
Electrode Stroke (MM) 100
Dimension(L*W*H) 950mm*800mm*1675mm
Warranty 1 year
Application Examples
HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding 5
HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding 6
HWASHI WL-MF-250K Vertical Type Medium Frequency Inverter Spot Welding Machine with 1000Hz Technology for Consistent Metal Sheet Welding 7
